A compact ultrafiltration system designed for reliable water treatment without external power.
Free-end UF membranes and automatic pressure backwashing provide stable filtration with low operating and maintenance requirements.A compact ultrafiltration system designed for reliable water treatment without external power.
Free-end UF membranes and automatic pressure backwashing provide stable filtration with low operating and maintenance requirements.
| Availability: | |
|---|---|
| Quantity: | |
Gravity Pure 01
0 kWh*
UF Operation
0.5–5 m³/h
Standard Capacity
Free-End UF
Membrane
Automatic
Backwash
Rural Water Supply
Mountain Areas
Islands
Emergency Water Supply
Off-Grid Communities
Water Station Upgrades
No Electricity
Power-free UF operation
Automatic Backwash
No electric pump required
Low Maintenance
Simple & reliable operation
Outdoor Ready
Compact stainless-steel design
⚡No Electricity
↻Automatic Backwash
Low Maintenance
▣Outdoor Ready
Free-End UF Membrane
Improved antifouling
Pressure-Driven Filtration
No external power
Automatic Pressure Backwash
Stable membrane operation
Modular Design
Easy installation & expansion
Available Models
| Model | Capacity | Footprint |
| UF-0.5 | 0.5 m³/h | 1 × 1 m |
| UF-1.0 | 1.0 m³/h | 1 × 1 m |
| UF-1.5 | 1.5 m³/h | 1 × 1 m |
| UF-2.0 | 2.0 m³/h | 1 × 1 m |
| UF-5.0 | 5.0 m³/h | 1 × 1 m |
| Customized | On Request | Customized |
Common Specifications
| Parameter | Specification |
| Filtration Technology | Ultrafiltration |
| Membrane Type | Free-End UF Membrane |
| Power Requirement | No External Power |
| Backwash | Automatic Pressure Backwash |
| Main Material | Stainless Steel |
| Standard Capacity | 0.5-5.0 m³/h |
| Installation | Outdoor/Minimal Civil Works |
| Customization | Available |
